M6-111

The M6 Series tractors come equipped with the class leading, 4-post Grand X Cab. This is one of the largest cabs in the mid-range utility tractor market, giving the operator excellent visibility with nearly a 360° around the tractor. Comfort is also included, with a standard air ride seat and controls ergonomically placed for ease of use and less fatigue for the operator.

Features include:

• High visibility roof panel, with the ability to open and close the window
• Air Ride seat with 15 degrees of swivel, adjustable backrest, headrest, and armrest. Specifically designed for absorbing shock
• Tilt and telescopic power steering
• 2 Displays
• Deluxe heating and air conditioning
• Optional instructor seat
• Optional defogger
• Optional rear shade

Proven, Powerful, and Reliable

The M6 Series is powered by two of the most powerful Kubota diesel engines in our line-up.

• M6-101/M6-111 – The V3800, 3.8 liter turbocharged engine boasts 97.1 and 106.8 net HP and is Tier 4 Final compliant. This Tier 4 Final, clean burning, fuel efficient engine is proven and widely used among Kubota’s M Series line of tractors.
• M6-131/M6-141 – The V6108, 6.1 liter turbocharged engine is the largest displacement engine in the mid-range utility class of tractor, providing 123.2 and 133.0 net HP. This Tier 4 Final compliant engine is as clean burning as it is mighty, giving you the power to work through the toughest conditions.

The M6 Series was built for seamless transitions through diverse terrains and operations. With features like Work Kruise, Dual RPM Memory, and Auto Mode, going from one functionality to the next can be smooth and effortless making the longest work days shorter.

When the operator moves the switch into the ON position, PTO will continue running when operator leaves the cab of the tractor.

The 2 Auto Mode options, Work and Travel, enable automatic shifting to maximize performance when your load or terrain changes. In Travel mode, the Intelli-Shift transmission will adjust to changes in the road conditions or desired vehicle speed, to maximize performance. In Field mode, the tractor will downshift 2 gears once the 3 point hitch is raised and keeps the PTO revolutions from dropping. This is beneficial when transitioning from light soil to heavy soil in a field or going from uphill to downhill. You can also adjust the sensitivity of shifting up and down gears.

Automatically keep engine revolutions constant and your PTO speed from dropping. This feature also makes operating PTO driven implements more efficient.

When precision and ultimate control is needed for rear attachments, operators will appreciate the deluxe flow-control rear remotes. This gives the M6 Series’ pressure compensated, fixed displacement hydraulic system infinite control and precise operation. With 18.7 (M6-101/M6-111) and 20.4 (M6-131/M6-141) gpm flow at the implement, are ready to power through any job. Flow of the remotes can easily be adjusted from inside the cab.

This allows the operator to choose how sensitive they want the gear shifts to be.

Kubota exclusive Bi-Speed Turn gives the operator the ability to navigate around tighter spots and make shorter end-row turns. When Bi-speed Turn is engaged, the front axle is driven 60% faster when the wheels are turned at a 35° or greater angle, pulling the front end of the tractor around and creating a tighter turn. This feature allows for the tractor to achieve a turning radius as low as 13.1’ (M6-101/111) and 13/8’ (M6-131/141).

Functions on the joystick includes shuttle inversion, gear shift button up & down, 3rd function, 4th function

We now have 2 USB Ports that come standard in all M6 series units.

Allows the operator to directly control the main clutch by simply pressing on the brake pedal. This enables the tractor to be stopped without engaging the clutch, ensuring maximum convenience and productivity

Built and designed with durability and longevity in mind, these Kubota designed and manufactured engines were built to last. The M6 Series comes in 4 different horsepower models and 2 different frame sizes. With the V3800 and the V6108 engines, the M6 Series tractors are ready to take on the task at hand.

All four models of M6 tractors feature Kubota’s 24 Speed Intelli-Shift transmission and an optional creep gear for a total F32/R32. The Intelli-Shift transmission features 8 powershift gears and 3 ranges Hi, Mi, and Low. Simply shift up or down in gears from the touch of a button, which is located on the shifting lever or conveniently on your deluxe armrest. With the powershift buttons and the range lever incorporated together, finding the right gear for field work or travel is simplified.
